SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat

SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat
SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat

Large Image :  SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat

Product Details:
Place of Origin: china
Model Number: SOP8-1.27-TPL1NT(7.5*11.5)
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $10
Packaging Details: 13*8*9cm
Delivery Time: 3-5 work days
Supply Ability: 3-5 work days
Contact Now

SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat

Description
Life Span: 10,000 Times Current Rating: 1A
Pitch: 1.27 Pin Count: 8pin
Operating Temperature: -45°C To +125°C Type1: Test & Burn In Socket ( Without Pcb )
Type2: Flash & Programming Model: Sop8-1.27

SOP8 small size wide body aging test stand, which is half the size of conventional SOP8 and is more accurate when placed in the clamp Smaller size, can save half of the aging board space, greatly improving aging efficiency.

Test seat model: SOP8 downward pressure type

IC body size: 7.5mm

IC foot size: 11.5mm

IC spacing: 1.27mm

IC packaging: SOP8

High and low temperature range: -45 ℃~+155 ℃SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat 0SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat 1SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat 2SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat 3SOP8-1.27 Lower Pressure Fragment Aging Seat 7.5mm High Temperature Resistance Test Seat HMILU Fixture Burning Seat 4
